$10000 ~~$10500~~

Categories: ATV / $3001-$80000 Brand: Non Brand SKU: Not available

Specifications

Engine Type：V-Twin, liquid cooled, 4-stroke, SOHC, 8-valve

Displacement：800cc

Maximum Power：75hp@7500rpm

Maximum Torque：70Nm@5500rpm

Fuel Supply：Bosch EFI

Power Modes：Sport/Normal/Work

Transmission：CVT, P-R-N-H-L

Length x Width x Height：2445 x 1264 x 1450mm

Wheelbase：1480mm

Ground Clearance：285mm

Curb Weight：465kg

Towing Capacity：820kg / 800kg EU

Load Capacity：300kg

Carry Capacity：45kg/90kg, CF-Connect with convertible racks

Winch：3500lbs

Fuel Capacity：26L

Colors

Tundra Grey/Lava Orange/True Timber Camo

Drive：2WD/4WD/4WD Lock (front differential)

EPS：Triple-Mode EPS

Brake：Four-wheel hydraulic disc brakes, single-piston caliper

Suspension

Front suspension: high clearance A-arm independent, 230mm travel

Rear suspension: trailing arm independent, 236mm travel

Shock Absorber：Coil spring shock absorbers with oil dampening

Rim

14-inch alloy

14-inch alloy Beadlock (premium)

Tire

Front: 26X9.00-14

Rear: 26X11.00-14
