Machinery Mall

| No Review

$11500 ~~$12000~~

Categories: ATV / $3001-$80000 Brand: Non Brand SKU: Not available

Specifications

Engine Type：V-twin, 4-stroke, liquid-cooled, DOHC

Displacement：963cc

Maximum Power：85hp@7500rpm

Maximum Torque：85N.m@5500rpm

Fuel Supply：Bosch EFI

Transmission：CVT, P-R-N-H-L

Length x Width x Height：2435×1282×1465 mm

Wheelbase：1480 mm

Minimum Ground Clearance：300 mm

Dry Weight：489kg

Payload Capacity：300 kg

Fuel Capacity：26 L

Colors：Forest Green, Desert Tan

Drive：2WD/4WD with locking differential

Brake：Four-wheel hydraulic disc brakes, single-piston caliper

Front Suspension：High clearance A-arm independent, 230mm travel

Rear Suspension：Trailing arm independent, 236mm travel

Shock Absorber：Coil spring shock absorbers with oil dampening

Rim：14-inch alloy

Front Tire：27x 9 R14

Rear Tire：27x 11 R14
