$4300 ~~$4500~~

Categories: ATV / $3001-$80000 Brand: Non Brand SKU: Not available

Specifications

Engine Type：Liquid-cooled four-stroke single cylinder with EFI

Displacement：400cc

Bore x Stroke：91x61.5mm

Maximum Power：31hp@7250 rpm

Maximum Torque：31N·m@5500rpm

Fuel Supply：EFI

Transmission：CVT transmission H/L/N/R/P

Length x Width x Height：2186 x 1157 x 1372 mm

Wheelbase：1260 mm

Minimum Ground Clearance：250 mm

Curb Weight：336 kg

Payload Capacity：240 kg

Fuel Capacity：17 L

Colors：Hunter Green/Lava Orange/Jet Black

Drive：2WD/4WD thumb control with 4WD differential lock

Brake：4-Wheel Hydraulic Disc

Suspension

Front:Arched Independent Dual A-Arm

Rear: Independent Dual A arm

Shock Absorber：Oil shocks with preload adjustable

Rim：12 inch steel

Tire：24 inch
